| Base ID | Configurable (Default H600) | ||
|---|---|---|---|
| Byte | Data | Data conversion | Resolution |
| 0:1 | RPM | Unsigned [msb:lsb] (Rpm) | 1RPM/bit |
| 2:3 | MAP | Unsigned [msb:lsb] (Kpa) | 1Kpa/bit |
| 4 | TPS(PPS) | Unsigned [byte] (%) | 0.5%/bit |
| 5 | DBW | Unsigned [byte] (%) | 0.5%/bit |
| 6:7 | Engine torque | Signed [msb:lsb] (NM) | 1NM/bit |
READ (old can type 6)
